Updated to CF16005LI
Installation | projector for outdoor applications (not suitable for use in swimming pools or fountains) |
---|---|
Power consumption | 2W |
Power supply | 24Vdc |
Lumen output at source | 145 lm (3000K) |
Delivered lumen output | 88 lm (3000K, 20°) |
Datasheet | Copied |
Mounting | surface mounted (ceiling, wall, ground, spike, strap) |
---|---|
Number and type of LED | 1 power LED, 1/4 ANSI BIN, 50 000h L90 B10 (Ta 25°C) |
LED colour | 3000K |
Optics | 40° |
CRI Colour Rendering Index | 80 |
Body material | body and trim in AISI 316L stainless steel |
Screen material | screen in transparent, tempered glass |
Power supply unit | power supply unit not included |
Power cables | includes 1.5 m neoprene cable, H05RN-F 2x0,35/0,75 Ø6,3 mm |
Ingress protection | IP68 |
Impact resistance | IK10 |
Notes | version with elliptical optics available on request |
Status | Available |
This product can be customized, thanks to our flexible in-house production. We suggest some of the possible customized versions on the right, but if you have any different requirements, we can review them together.
Accessories for product code CF16005LI
WP0100Spike for in-ground installation |
Order together with the lighting fixture.WH0101Honeycomb louvrebuilt into the lighting fixture The honeycomb louvre can be fitted on all fixed optics, except for sharp optics |
WB0320IStandard snoot - stainless steel |
WB0321IAsymmetrical snoot - stainless steel |
WP1004Fastener strap - 5 m |
Power supply units for product code CF16005LI
Control gear for product code CF16005LI
ADV576DALIN1Low-voltage dimmerorder in addition to PSU
|
ARVUNID2-01Universal sequencer - Low-voltage 4-channel controller with constant-voltage outputorder in addition to PSU
|
||||||||||||||||
EC0CEN12445A20Low-voltage 4-channel controller with constant-voltage output for CASAMBIWhite, dynamic white, RGB, RGBW, RGB+W
|
EC0CEN1244DA20Low-voltage dimmer for CASAMBIorder in addition to PSU
|
