Ello OUT 2.0

Ceiling mounted for outdoor applications

ceiling mounted for outoor applications - 16W 230Vac - 208 mm

Generate code

Technical data

Print technical data
  • complies with the European standard EN 60598-1
  • EAC
  • lighting fixture with LED technology
  • gross weight
    kg 0,80
  • IP65
  • IK08
  • RAL finish on request
  • A/A+/A++
Installation ceiling mounted for outoor applications
Power consumption 16W
Power supply 230Vac
Lumen output at source 1908 lm (3000K)
Delivered lumen output 985 lm (3000K)


Mounting surface mounted (ceiling)
Number and type of LED 36 mid power LEDs, 3-step MacAdam, 50 000h L80 B10 (Ta 25°C)
LED colour 2700K, 3000K, 4000K
Optics diffuse
CRI Colour Rendering Index 80
Body material body in aluminium
Screen material screen in serigraphed extra-clear microprismatic glass
Finishes cor-ten, white, anthracite, grey
Power supply unit built-in power supply unit
Power cables includes 1,5 m neoprene cable, H05RN-F 3x1,0 Ø7 mm
Ingress protection IP65
Impact resistance IK08
Status Available
