Duomo 1.0

Projectors for outdoor applications

projector for outdoor applications - 10W 230Vac

Generate code

Technical data

Print technical data
  • CE mark for the European Union
  • UKCA mark for Great Britain
  • EAC
  • lighting fixture with LED technology
  • appliance class II
  • gross weight
    kg 0,80
  • IP65
  • IK06
  • PID
  • RAL finish on request
  • F
Installation projector for outdoor applications
Power consumption 10W
Power supply 230Vac
Lumen output at source 815 lm (3000K, CRI 90),
880 lm (3000K, CRI 80)
Delivered lumen output 661 lm (3000K, 30°, CRI 90),
714 lm (3000K, 30°, CRI 80)
Datasheet

Copied

Mounting surface mounted (ceiling, wall, floor)
Number and type of LED 2 power LEDs High Intensity, 3-step MacAdam, 50 000h L90 B10 (Ta 25°C)
LED colour 2700K, 3000K, 4000K
Optics 10°, 14°, 30°, 35°, 43°, 63°, 18°x44°, 44°x18°
CRI Colour Rendering Index 80, >90
Body material body and arm in Anticorodal aluminium
Screen material screen in serigraphed, tempered, extra-clear glass
Finishes white, antique white, anthracite
Power supply unit built-in power supply unit
Control system ON/OFF
Ingress protection IP65
Impact resistance IK06
Features Fast installation: direct connection between fixture and mains power supply
Notes available on request with adapter for Eurostandard track and in DALI, 0/1-10V or PUSH version, or with Bluetooth control,
Casambi-compatible version, controllable with the Casambi app, available on request
Status Available
