Plin 4.2
Bollards for outdoor applications
bollard for outdoor applications - 8W 230Vac - diffuse optics - h 820 mm
Bollards for outdoor applications
bollard for outdoor applications - 8W 230Vac - diffuse optics - h 820 mm
Updated to PN421005DT
Installation | bollard for outdoor applications |
---|---|
Power consumption | 8W |
Power supply | 230Vac |
Lumen output at source | 488 lm (3000K) |
Delivered lumen output | 423 lm (3000K) |
Datasheet | Copied |
Mounting | surface mounted (floor) |
---|---|
Number and type of LED | 1 power LED, 3-step MacAdam, 50 000h L90 B10 (Ta 25°C) |
LED colour | 3000K |
Optics | diffuse |
CRI Colour Rendering Index | 80 |
Body material | head in aluminium, column in AISI 316L stainless steel |
Screen material | screen in serigraphed, transparent, tempered extra-clear glass |
Finishes | cor-ten |
Power supply unit | built-in power supply unit |
Ingress protection | IP65 |
Impact resistance | IK07 |
Notes | non-standard heights available on request, Casambi-compatible version, controllable with the Casambi app, available on request |
Status | Available |
This product can be customized, thanks to our flexible in-house production. We suggest some of the possible customized versions on the right, but if you have any different requirements, we can review them together.
Accessories for product code PN421005DT
WPA00Spike for in-ground installation |
Power supply units for product code PN421005DT
No power supply units
Control gear for product code PN421005DT
No controllers
No control inputs
