Plin 3.2

Bollards for outdoor applications

bollard for outdoor applications - 24W 230Vac - double beam - diffuse, asymmetrical optics - h 760 mm

Generate code

Technical data

Print technical data
  • complies with the European standard EN 60598-1
  • EAC
  • lighting fixture with LED technology
  • gross weight
    kg 2,35
  • IP65
  • IK08
  • RAL finish on request
  • A/A+/A++
Installation bollard for outdoor applications, double beam
Power consumption 24W
Power supply 230Vac
Lumen output at source 1242 lm (3000K) per beam
Delivered lumen output 492 lm (3000K) per beam


Mounting surface mounted (floor)
Number and type of LED 36 mid power LEDs, 3-step MacAdam, 50 000h L85 B10 (Ta 25°C)
LED colour 2700K, 3000K, 4000K
Optics diffuse, asymmetrical
CRI Colour Rendering Index 80
Body material head and column in aluminium
Screen material screen in serigraphed, tempered, transparent extra-clear glass
Finishes anthracite, white, grey, cor-ten
Power supply unit built-in power supply unit
Ingress protection IP65
Impact resistance IK08
Notes non-standard heights available on request
Status Available
