Teko 5.0

5/9W 230Vac - diffuse optics - 80x80x81 mm

Generate code

Technical data

Print technical data
  • complies with the European standard EN 60598-1
  • lighting fixture with LED technology
  • gross weight
    kg 0,53
  • IP40
  • RAL finish on request
  • A/A+/A++
Installation ceiling mounted for indoor applications
Power 5W, 9W
Power supply 230Vac
Lumen output at source 826 lm (3000K, 9W),
460 lm (3000K, 5W)
Delivered lumen output 590 lm (3000K, 9W),
330 lm (3000K, 5W)
Datasheet

Copied

Mounting surface mounted (ceiling)
Number and type of LED power LED matrix, 3-step MacAdam, 50 000h L80 B10 (Ta 25°C)
LED colour 2700K, 3000K, 4000K
Optics diffuse
Body material body in anodized aluminium
Screen material screen in one-side-frosted, transparent plexiglass
Finishes white
Power supply unit built-in power supply unit
Power cables terminal block
Ingress protection IP40
Status Available
