Altopiano 1.6

Recessed for outdoor applications

recessed for outdoor applications - 9W 110-230Vac - Ø98 mm - Dim to Warm: 1800K — 3000K - DALI-2

Generate code

Customize this product

This product can be customized, thanks to our flexible in-house production. We suggest some of the possible customized versions on the right, but if you have any different requirements, we can review them together.

Possible customizations:

  • Screen in white-serigraphed glass

Technical data

Print technical data
  • dim to warm
  • CE mark for the European Union
  • UKCA mark for Great Britain
  • CB
  • EAC
  • lighting fixture with LED technology
  • appliance class II
  • gross weight
    0,6 kg
  • cut-out size
    Ø90 mm
  • IP66
  • IK08
  • DALI-2
  • RAL finish on request
  • primer
  • F
Installation recessed for outdoor applications
Power consumption 9W
Power supply 110-230Vac
Lumen output at source 611 lm (3000K)
Delivered lumen output 372 lm (3000K, 27°)
Datasheet

Copied

Mounting recessed (ceiling)
Number and type of LED 1 COB LED, 3-step MacAdam, 55 000h L90 B10 (Ta 25°C)
LED colour Dim to Warm: 1800K — 3000K
Optics 22°, 26°, 37°, 51°, 25°x65°, diffuse
CRI Colour Rendering Index >90
Body material body in thermally conductive technopolymer, trim in stainless steel
Screen material screen in serigraphed-grey and transparent, tempered extra-clear glass
Finishes grey, cor-ten, white, anthracite, primer
Power supply unit power supply unit included
Power cables includes 0.50 m neoprene cable, H07RN-F 2x1.0 Ø8.0 mm
Control system DALI-2
Ingress protection IP66
Impact resistance IK08
Notes Casambi-compatible version, controllable with the Casambi app, available on request
Status Available
