Colorado 2.1

Linear profiles for outdoor applications

linear profile for outdoor applications - 62W 230Vac - 932 mm

Generate code

Technical data

Print technical data
  • conforme alla normativa Europea EN 60598-1
  • EAC
  • lighting fixture with LED technology
  • appliance class II
  • drive-over fixture
    kg 1500 - kN 15
  • gross weight
    kg 8,6
  • IP65
  • IP67
  • IK10
  • PID
  • DALI
  • 0/1-10V
  • maximum device temperature40°C
  • A/A+/A++
Installation linear profile for outdoor applications
Power consumption 62W
Power supply 230Vac
Lumen output at source 7425 lm (3000K)
Delivered lumen output 5645 lm (3000K, 12°)
Datasheet

Copied

Mounting recessed (floor)
Number and type of LED 27 high power LEDs pitch 20 mm, 2-step MacAdam, 60000h L80 B10 (Ta 25°C)
2200K: 3-step MacAdam, 60000h L80 B10 (Ta 25°C)
LED colour 2200K, 2700K, 3000K, 4000K
Optics 12° tiltable ±20°, 30° tiltable ±20°, 45° tiltable ±20°, 76° tiltable ±20°, 15°x50° tiltable ±20°, diffuse tiltable ±20°
CRI Colour Rendering Index 80
Body material body in black-anodized anticorodal aluminium, caps in technopolymer
Screen material screen in serigraphed-grey and transparent, tempered extra-clear glass,
screen in grey-serigraphed, acid-etched, tempered extra-clear glass (diffuse version)
Power supply unit built-in power supply unit
Control system 0/1-10V, DALI, ON/OFF
Ingress protection IP65, IP67
Impact resistance IK10
Features optical accessories of honeycomb louvre and anti-glare shield built into the lighting fixture and tiltable together with the optics.
In/out connection and easy wiring with quick connectors designed to connect the profiles one after the other
Notes Casambi-compatible version, controllable with the Casambi app, available on request
Status Available
