Flori 1.2

Projectors for outdoor applications

projector for outdoor applications - 13W 24Vdc - adjustable 250° - RGBW

Technical data

Print technical data

kg 0,80
IP66
IK07

Installation	projector for outdoor applications
Power consumption	13W
Power supply	24Vdc
Lumen output at source	512 lm, R: 88 lm G: 160 lm B: 52 lm W: 212 lm (4000K)
Delivered lumen output	304 lm, R: 52 lm G: 95 lm B: 31 lm W: 126 lm (4000K, 33°)
Datasheet	Flori 1.2 projector for outdoor applications; surface mounted (ceiling, wall, ground, spike, strap); Power consumption: 13W; Power supply: 24Vdc; Lumen output at source: 512 lm, R: 88 lm G: 160 lm B: 52 lm W: 212 lm (4000K); Delivered lumen output: 304 lm, R: 52 lm G: 95 lm B: 31 lm W: 126 lm (4000K, 33°); 1 RGBW LED group, 50 000h L85 B10 (Ta 25°C); LED colour: RGBW; Optics: 24°, 33°, 60°, 32°x61°, 61°x32°: optical system consisting of a high-efficiency TIR lens combined with a high-quality technical filter; Body material: body made of ANTICORODAL 6082 low-copper-content aluminium alloy for excellent resistance to corrosion, made entirely on a CNC lathe. Bracket in painted AISI 316L stainless steel; Finishes: white finish obtained through an initial treatment with a ceramic nanoparticle coating, to prepare for painting, followed by a coat of epoxy paint and one of polyester paint to provide corrosion resistance of more than 1500 hours of salt spray. Paints compliant with the Qualicoat standard used in the automotive sector (RAL 9003), grey finish obtained through an initial treatment with a ceramic nanoparticle coating, to prepare for painting, followed by a coat of epoxy paint and one of polyester paint to provide corrosion resistance of more than 1500 hours of salt spray. Paints compliant with the Qualicoat standard used in the automotive sector (RAL 9006), cor-ten finish obtained through an initial treatment with a ceramic nanoparticle coating, to prepare for painting, followed by a coat of epoxy paint and one of polyester paint to provide corrosion resistance of more than 1500 hours of salt spray. Paints compliant with the Qualicoat standard used in the automotive sector, anthracite finish obtained through an initial treatment with a ceramic nanoparticle coating, to prepare for painting, followed by a coat of epoxy paint and one of polyester paint to provide corrosion resistance of more than 1500 hours of salt spray. Paints compliant with the Qualicoat standard used in the automotive sector; RAL finish on request; Screen material: 4-mm-thick transparent extra-clear glass with vitrified serigraphy, high transmittance to ensure chromatic uniformity of light and tempered for excellent resistance to knocks and scratches; power supply unit not included; includes 1.5 m FEP+RUB cable (equivalent to H05RN-F cable) 6x0.50/0.50 Ø6.3 mm; Ingress protection: IP66; Impact resistance: IK07; Casambi-compatible version, controllable with the Casambi app, available on request, Casambi-compatible version, controllable with the Casambi app, available on request; Protection systems: IPS (Intelligent Protection System) protects lighting fixtures from water infiltrations, which can occur if there are faulty junctions between the cables in outdoor or underwater applications. This innovation, patented by L&L, also guarantees electrical protection against polarity reversal, hot plugging, ESD and power surges, which can occur if there are faults in the electrical circuit; The PID (Protective Impedance Device) protects lighting fixtures from electrical phenomena external to the system, such as static electricity accumulation or electromagnetic interference coming from the mains power. Generally, these are events with a low energy content; Operating temperature: -20°C — +45°C; Glow wire test: 960°; Photobiological safety: photobiological safety: risk group 1 according to EN 62471:2006; Appliance class: class III; Weight: 800 g; Dimensions: Ø60x154x147 mm; Energy efficiency class: A / A+ / A++ (integrated LED module) in accordance with UE 874/2012; Accessories: WB1001E Standard snoot - white, WB1001F Standard snoot - grey, WB1001H Standard snoot - anthracite, WB1001T Standard snoot - cor-ten, WB1002E Asymmetrical snoot - white, WB1002F Asymmetrical snoot - grey, WB1002H Asymmetrical snoot - anthracite, WB1002T Asymmetrical snoot - cor-ten, WB1003N Barn doors - black, WH0203 Honeycomb louvre , WP0100 Spike for in-ground installation, WP1001E Spike with bracket for in-ground installation - h 500 mm - white, WP1001F Spike with bracket for in-ground installation - h 500 mm - grey, WP1001H Spike with bracket for in-ground installation - h 500 mm - anthracite, WP1001T Spike with bracket for in-ground installation - h 500 mm - cor-ten, WP1002E Spike with bracket for in-ground installation - h 800 mm - white, WP1002F Spike with bracket for in-ground installation - h 800 mm - grey, WP1002H Spike with bracket for in-ground installation - h 800 mm - anthracite, WP1002T Spike with bracket for in-ground installation - h 800 mm - cor-ten, WP1003E Arm with bracket for wall-mounted installation - h 420 mm - white, WP1003F Arm with bracket for wall-mounted installation - h 420 mm - grey, WP1003H Arm with bracket for wall-mounted installation - h 420 mm - anthracite, WP1003T Arm with bracket for wall-mounted installation - h 420 mm - cor-ten, WP1004 Fastener strap - 5 m; tested and approved via E.O.L. (End Of Line) test with functioning test and check of electrical power consumptionFlori 1.2 projector for outdoor applications surface mounted (ceiling, wall, ground, spike, strap) Power consumption: 13W Power supply: 24Vdc Lumen output at source: 512 lm, R: 88 lm G: 160 lm B: 52 lm W: 212 lm (4000K) Delivered lumen output: 304 lm, R: 52 lm G: 95 lm B: 31 lm W: 126 lm (4000K, 33°) 1 RGBW LED group, 50 000h L85 B10 (Ta 25°C) LED colour: RGBW Optics: 24°, 33°, 60°, 32°x61°, 61°x32°: optical system consisting of a high-efficiency TIR lens combined with a high-quality technical filter Body material: body made of ANTICORODAL 6082 low-copper-content aluminium alloy for excellent resistance to corrosion, made entirely on a CNC lathe. Bracket in painted AISI 316L stainless steel Finishes: white finish obtained through an initial treatment with a ceramic nanoparticle coating, to prepare for painting, followed by a coat of epoxy paint and one of polyester paint to provide corrosion resistance of more than 1500 hours of salt spray. Paints compliant with the Qualicoat standard used in the automotive sector (RAL 9003), grey finish obtained through an initial treatment with a ceramic nanoparticle coating, to prepare for painting, followed by a coat of epoxy paint and one of polyester paint to provide corrosion resistance of more than 1500 hours of salt spray. Paints compliant with the Qualicoat standard used in the automotive sector (RAL 9006), cor-ten finish obtained through an initial treatment with a ceramic nanoparticle coating, to prepare for painting, followed by a coat of epoxy paint and one of polyester paint to provide corrosion resistance of more than 1500 hours of salt spray. Paints compliant with the Qualicoat standard used in the automotive sector, anthracite finish obtained through an initial treatment with a ceramic nanoparticle coating, to prepare for painting, followed by a coat of epoxy paint and one of polyester paint to provide corrosion resistance of more than 1500 hours of salt spray. Paints compliant with the Qualicoat standard used in the automotive sector RAL finish on request Screen material: 4-mm-thick transparent extra-clear glass with vitrified serigraphy, high transmittance to ensure chromatic uniformity of light and tempered for excellent resistance to knocks and scratches power supply unit not included includes 1.5 m FEP+RUB cable (equivalent to H05RN-F cable) 6x0.50/0.50 Ø6.3 mm Ingress protection: IP66 Impact resistance: IK07 Casambi-compatible version, controllable with the Casambi app, available on request, Casambi-compatible version, controllable with the Casambi app, available on request Protection systems: IPS (Intelligent Protection System) protects lighting fixtures from water infiltrations, which can occur if there are faulty junctions between the cables in outdoor or underwater applications. This innovation, patented by L&L, also guarantees electrical protection against polarity reversal, hot plugging, ESD and power surges, which can occur if there are faults in the electrical circuit; The PID (Protective Impedance Device) protects lighting fixtures from electrical phenomena external to the system, such as static electricity accumulation or electromagnetic interference coming from the mains power. Generally, these are events with a low energy content Operating temperature: -20°C — +45°C Glow wire test: 960° Photobiological safety: photobiological safety: risk group 1 according to EN 62471:2006 Appliance class: class III Weight: 800 g Dimensions: Ø60x154x147 mm Energy efficiency class: A / A+ / A++ (integrated LED module) in accordance with UE 874/2012 Accessories: WB1001E Standard snoot - white, WB1001F Standard snoot - grey, WB1001H Standard snoot - anthracite, WB1001T Standard snoot - cor-ten, WB1002E Asymmetrical snoot - white, WB1002F Asymmetrical snoot - grey, WB1002H Asymmetrical snoot - anthracite, WB1002T Asymmetrical snoot - cor-ten, WB1003N Barn doors - black, WH0203 Honeycomb louvre , WP0100 Spike for in-ground installation, WP1001E Spike with bracket for in-ground installation - h 500 mm - white, WP1001F Spike with bracket for in-ground installation - h 500 mm - grey, WP1001H Spike with bracket for in-ground installation - h 500 mm - anthracite, WP1001T Spike with bracket for in-ground installation - h 500 mm - cor-ten, WP1002E Spike with bracket for in-ground installation - h 800 mm - white, WP1002F Spike with bracket for in-ground installation - h 800 mm - grey, WP1002H Spike with bracket for in-ground installation - h 800 mm - anthracite, WP1002T Spike with bracket for in-ground installation - h 800 mm - cor-ten, WP1003E Arm with bracket for wall-mounted installation - h 420 mm - white, WP1003F Arm with bracket for wall-mounted installation - h 420 mm - grey, WP1003H Arm with bracket for wall-mounted installation - h 420 mm - anthracite, WP1003T Arm with bracket for wall-mounted installation - h 420 mm - cor-ten, WP1004 Fastener strap - 5 m tested and approved via E.O.L. (End Of Line) test with functioning test and check of electrical power consumption Copied

Mounting	surface mounted (ceiling, wall, ground, spike, strap)
Number and type of LED	1 RGBW LED group, 50 000h L85 B10 (Ta 25°C)
LED colour	RGBW
Optics	24°, 33°, 60°, 32°x61°, 61°x32°
Body material	body in aluminium
Screen material	screen in serigraphed, transparent, tempered extra-clear glass
Finishes	white, grey, cor-ten, anthracite
Power supply unit	power supply unit not included
Power cables	includes 1.5 m FEP+RUB cable (equivalent to H05RN-F cable) 6x0.50/0.50 Ø6.3 mm
Ingress protection	IP66
Impact resistance	IK07
Notes	Casambi-compatible version, controllable with the Casambi app, available on request, Casambi-compatible version, controllable with the Casambi app, available on request
Status	Available

Read more

Close

Download

See all downloads

Gallery

Accessories and power supply units

Accessories (24)

Spikes and arms

WP0100 Spike for in-ground installation	WP1001E Spike with bracket for in-ground installation - h 500 mm - white
WP1001F Spike with bracket for in-ground installation - h 500 mm - grey	WP1001H Spike with bracket for in-ground installation - h 500 mm - anthracite
WP1001T Spike with bracket for in-ground installation - h 500 mm - cor-ten	WP1002E Spike with bracket for in-ground installation - h 800 mm - white
WP1002F Spike with bracket for in-ground installation - h 800 mm - grey	WP1002H Spike with bracket for in-ground installation - h 800 mm - anthracite
WP1002T Spike with bracket for in-ground installation - h 800 mm - cor-ten	WP1003E Arm with bracket for wall-mounted installation - h 420 mm - white
WP1003F Arm with bracket for wall-mounted installation - h 420 mm - grey	WP1003H Arm with bracket for wall-mounted installation - h 420 mm - anthracite
WP1003T Arm with bracket for wall-mounted installation - h 420 mm - cor-ten

Honeycomb louvre

Order together with the lighting fixture.

WH0203

Honeycomb louvre

built into the lighting fixture

Snoots

WB1001E Standard snoot - white	WB1001F Standard snoot - grey
WB1001H Standard snoot - anthracite	WB1001T Standard snoot - cor-ten
WB1002E Asymmetrical snoot - white	WB1002F Asymmetrical snoot - grey
WB1002H Asymmetrical snoot - anthracite	WB1002T Asymmetrical snoot - cor-ten

Barn doors

WB1003N

Barn doors - black

Various accessories

WP1004

Fastener strap - 5 m

Power supply units (16)

ACUNI020T1

ON/OFF constant-current PSU

Input	230Vac 50-60 Hz
Output	24Vdc; 16W 250mA constant current; max 13W 350mA constant current; max 19W 400mA constant current; max 20W 450mA constant current; max 20W 500mA constant current; max 20W 550mA constant current; max 20W 600mA constant current; max 20W 700mA constant current; max 20W
Dimmering	Cannot be dimmed
Power supply unit IP	IP20

ACUNI032T1

ON/OFF constant-current PSU

Input	230Vac 50-60 Hz
Output	24Vdc; 20W 12Vdc; 10W 28Vdc; 22W 350mA constant current; max 17W 500mA constant current; max 24W 550mA constant current; max 25W 700mA constant current; max 32W
Dimmering	Cannot be dimmed
Power supply unit IP	IP20

AD032TLT1

Dimmable power supply unit

Input	230Vac 50-60 Hz
Output	24Vdc; 20W 12Vdc; 10W 28Vdc; 22W 350mA constant current; max 17W 500mA constant current; max 24W 550mA constant current; max 25W 700mA constant current; max 32W 750mA constant current; max 32W
Dimmering	PUSH, Mains dimming, ON/OFF
Power supply unit IP	IP20

ADUNITC

1-10V+PUSH dimmable power supply unit

Input	115-230Vac 50-60 Hz 230Vac 50-60 Hz
Output	24Vdc; 20W 12Vdc; 11W 250mA constant current; max 13W 300mA constant current; max 16W 350mA constant current; max 18W 400mA constant current; max 21W 450mA constant current; max 23W 500mA constant current; max 25W 550mA constant current; max 27W 600mA constant current; max 30W 650mA constant current; max 32W 700mA constant current; max 32W 750mA constant current; max 20W 800mA constant current; max 20W 850mA constant current; max 20W 900mA constant current; max 20W
Dimmering	0/1-10V, PUSH, ON/OFF
Power supply unit IP	IP20

AV00002406020

ON/OFF constant-voltage PSU

Input	230Vac 50-60 Hz
Output	24Vdc; 60W
Power	60W
Dimmering	ON/OFF
Power supply unit IP	IP20

AV00002412020

ON/OFF constant-voltage PSU

Input	230Vac 50-60 Hz
Output	24Vdc; 120W
Power	120W
Dimmering	ON/OFF
Power supply unit IP	IP20

AV00002418020

ON/OFF constant-voltage PSU

Input	230Vac 50-60 Hz
Output	24Vdc; 180W
Power	180W
Dimmering	ON/OFF
Power supply unit IP	IP20

AV24020IP67

ON/OFF constant-voltage PSU

Input	115-230Vac 50-60 Hz 230Vac 50-60 Hz
Output	24Vdc; 20W
Dimmering	ON/OFF
Power supply unit IP	IP67

AV24040IP67

ON/OFF constant-voltage PSU

Input	115-230Vac 50-60 Hz 230Vac 50-60 Hz
Output	24Vdc; 40W
Dimmering	ON/OFF
Power supply unit IP	IP67

AV24060IP20

ON/OFF constant-voltage PSU

Input	230Vac 50-60 Hz
Output	24Vdc; 60W
Dimmering	ON/OFF
Power supply unit IP	IP20

AV24060IP67

ON/OFF constant-voltage PSU

Input	115-230Vac 50-60 Hz 230Vac 50-60 Hz
Output	24Vdc; 60W
Dimmering	ON/OFF
Power supply unit IP	IP67

AV24100IP20

ON/OFF constant-voltage PSU

Input	230Vac 50-60 Hz
Output	24Vdc; 100W
Dimmering	ON/OFF
Power supply unit IP	IP20

AV24150IP20

ON/OFF constant-voltage PSU

Input	230Vac 50-60 Hz
Output	24Vdc; 150W
Power	150W
Dimmering	ON/OFF
Power supply unit IP	IP20

AV24150IP67

ON/OFF constant-voltage PSU

Input	115-230Vac 50-60 Hz 230Vac 50-60 Hz
Output	24Vdc; 150W
Dimmering	ON/OFF
Power supply unit IP	IP67

AV24240IP67

ON/OFF constant-voltage PSU

Input	115-230Vac 50-60 Hz 230Vac 50-60 Hz
Output	24Vdc; 240W
Dimmering	ON/OFF
Power supply unit IP	IP67

AV24320IP67

ON/OFF constant-voltage PSU

Input	115-230Vac 50-60 Hz 230Vac 50-60 Hz
Output	24Vdc; 320W
Dimmering	ON/OFF
Power supply unit IP	IP67

Control gear (5)

ARVUNID2

Universal sequencer - Low-voltage 4-channel controller with constant-voltage output

order in addition to PSU

Input	12-24Vdc
Output	4 channels With 24 Vdc input:; 24Vdc; 384W 1 channel With 12 Vdc input:; 12Vdc; 60W With 24 Vdc input:; 24Vdc; 120W 2 channels With 12 Vdc input:; 12Vdc; 192W With 24 Vdc input:; 24Vdc; 384W 3 channels With 12 Vdc input:; 12Vdc; 180W With 24 Vdc input:; 24Vdc; 360W 4 channels With 12 Vdc input:; 12Vdc; 192W
Dimmering	0/1-10V, PUSH, DALI, ON/OFF, 10kΩ potentiometer, DMX512, DMX512+RDM, Stand alone
Power supply unit IP	IP20

EC0CEN12445A20

Low-voltage 4-channel controller with constant-voltage output for CASAMBI

White, dynamic white, RGB, RGBW, RGB+W
order in addition to PSU

Input	12-24Vdc 24Vdc
Output	4 channels With 24 Vdc input:; 24Vdc; 240W 1 channel With 12 Vdc input:; 12Vdc; 60W With 24 Vdc input:; 24Vdc; 120W 2 channels With 12 Vdc input:; 12Vdc; 120W With 24 Vdc input:; 24Vdc; 240W 3 channels With 12 Vdc input:; 12Vdc; 120W With 24 Vdc input:; 24Vdc; 240W 4 channels With 12 Vdc input:; 12Vdc; 120W
Dimmering	PUSH
Power supply unit IP	IP20

ECCTR1244CV20

Router / controller WIFI/RF 4x4A RGBW

order in addition to PSU

Input	12-24Vdc
Output	With 24 Vdc input:; 24Vdc; 384W With 12 Vdc input:; 12Vdc; 192W
Dimmering	Radio frequency
Power supply unit IP	IP20

ECCTS5244CV20

RGB/RGBW controller with integrated 4-channel receiver

order in addition to PSU
to be used with TOUCH03L1, TOUCH02L1 e ECCTR1244CV20

Input	12-24Vdc
Output	With 24 Vdc input:; 24Vdc; 480W With 12 Vdc input:; 12Vdc; 240W
Dimmering	Radio frequency
Power supply unit IP	IP20

TLR02-01

Controller with integrated 4-channel receiver for RGB/RGBW/dynamic white/dimming

order in addition to PSU
RGB/RGBW: Required TLC08 or TLC09 remote control, not included
Dynamic white/dimming: PUSH switch

Input	12-24Vdc
Output	4 channels With 24 Vdc input:; 24Vdc; 240W 3 channels With 12 Vdc input:; 12Vdc; 90W With 24 Vdc input:; 24Vdc; 180W 4 channels With 12 Vdc input:; 12Vdc; 120W
Dimmering	PUSH, Stand alone, Radio frequency
Power supply unit IP	IP20

Control input (9)

ECPNL2301DM20

Touch-screen device

Required outer casing not included

Input	115-230 Vac 50-60Hz
Output	DMX512 bus, WiFi, RF
Ingress protection	IP20
Dimensions	178x33x48 mm 230 g
Control	touch RGBW

TLC08

Remote control for TLR02-01, TLR04M-350-500 and TLR04M-350-700 controllers

Input	CR2450 battery
Output	433,92 MHz
Ingress protection	IP20
Dimensions	40x40x10 mm

TLC09

Remote control for TLR02-01, TLR04M-350-500 and TLR04M-350-700 controllers

Input	CR2450 battery
Output	433,92 MHz
Ingress protection	IP20
Dimensions	40x40x10 mm

TLC15

1-channel remote control for TLR07

Input	CR2450 battery
Output	433.92 MHz
Ingress protection	IP20
Dimensions	40x40x10 mm
Range	100 m (40m indoors)

TLC16

2-channel remote control for TLR07

Input	CR2450 battery
Output	433.92 MHz
Ingress protection	IP20
Dimensions	40x40x10 mm
Range	100 m (40 m indoors)

TLC17

4-channel remote control for TLR07

Input	CR2450 battery
Output	433.92 MHz
Ingress protection	IP20
Dimensions	40x40x10 mm
Range	100 m (40 m indoors)

TLR07

2-channel receiver for TLC15, TLC16, TLC17 remote control

(1/2 NO push buttons)

Input	110-230Vac 50/60Hz
Output	2 clean contacts
Ingress protection	IP20
Dimensions	58x43x21 mm
Cutout dimensions	Ø50 mm

TOUCH02L1

Touch-screen device

Required outer casing not included WC0302

Input	100—240Vac
Output	DMX512 bus, WiFi, RF
Ingress protection	IP20
Dimensions	86x86x36 mm 225 g
Control	Touch RGBW

TOUCH03L1

Touch-screen device

Required outer casing not included WC0302

Input	100—240Vac
Output	DMX512 bus, WiFi, RF
Ingress protection	IP20
Dimensions	86x86x36 mm 225 g
Control	touch RGBW
