AR330350TC

Home RGB

Input230Vac 50-60 Hz
Output350mA constant current; max 36W
DimmeringPUSH, DMX512, Stand alone
Power supply unit IPIP20

PDF Instruction sheetPDF Technical sheet

Control input:

DMX01

DMX Controller

Input230Vac
OutputDMX512 bus
Dimensions79x92x43 mm, 120 g

TLC05

Radio control with 4 channels

Input1 x 12V alkaline battery
Output433,90 MHz
Ingress protectionIP20
DimensionsØ85x28 mm

TLC06

Radio control with 2 channels

Input1 x 3V CR2025 battery
Output433,90 MHz
Ingress protectionIP20
Dimensions55x28x10 mm

TLC15

1-channel remote control for TLR07

InputCR2450 battery
Output433.92 MHz
Ingress protectionIP20
Dimensions40x40x10 mm
Range100 m (40m indoors)

TLC16

2-channel remote control for TLR07

InputCR2450 battery
Output433.92 MHz
Ingress protectionIP20
Dimensions40x40x10 mm
Range100 m (40 m indoors)

TLC17

4-channel remote control for TLR07

InputCR2450 battery
Output433.92 MHz
Ingress protectionIP20
Dimensions40x40x10 mm
Range100 m (40 m indoors)

TLR01

Receiver required for TLC05 and TLC06 remote control

Input12─24Vdc
Output2 clean contacts
Ingress protectionIP20
Dimensions90x53x28 mm

TLR07

2-channel receiver for TLC15, TLC16, TLC17 remote control

(1/2 NO push buttons)

Input110-230Vac 50/60Hz
Output2 clean contacts
Ingress protectionIP20
Dimensions58x43x21 mm
Cutout dimensionsØ50 mm

TOUCH02L1

Touch-screen device

Required outer casing not included WC0302

Input100—240Vac
OutputDMX512 bus, WiFi, RF
Ingress protectionIP20
Dimensions86x86x36 mm 225 g
ControlTouch RGBW

TOUCH03L1

Touch-screen device

Required outer casing not included WC0302

Input100—240Vac
OutputDMX512 bus, WiFi, RF
Ingress protectionIP20
Dimensions86x86x36 mm 225 g
Controltouch RGBW
