City 1.0

Strahler für den Innenbereich

Strahler für den Innenbereich - max 3W max 350mA

Artikelnummer generieren

Technische Daten

Technische Daten drucken
  • CE-Konformitätszeichen für die Europäische Union
  • UKCA- Konformitätszeichen für Großbritannien
  • EAC
  • Leuchte mit LED-Technologie
  • Schutzklasse III
  • Bruttogewicht
    kg 0,20
  • IP20
  • auf Wunsch RAL-Finish
  • Casambi-Lichtsteuerung
  • F
Montageart Strahler für den Innenbereich
Leistungsaufnahme max 3W (3 Power-LEDs x 2W)
Stromversorgung max 350mA
Lichtstrom Lichtquelle 331 lm (3000K, 350mA)
Leuchtenlichtstrom 221 lm (3000K, 350mA, 25°)
Leistungsverzeichnis

Kopiert

Montage an Oberfläche (Schaufenster)
LED-Anzahl und Art 3 Power-LEDs, 1/4 ANSI BIN, 50000h L90 B10 (Ta 25°C)
LED-Farbe 3000K, 4000K, 5000K
Optiken 10°, 25°, 40°
CRI Farbwiedergabeindex 80
Material Leuchtenkörper Körper aus Aluminium, Arm aus Messing
Oberflächenausführungen satiniert, Chrom
Netzteil Netzteil nicht inbegriffen
Anschluss Reihenschaltung
Stromkabel 0,50 m PVC-Kabel, FROR 2x0,35 Ø3,5 mm, inbegriffen
Schutzart IP20
Bemerkungen Standrohr auf Anfrage in Sonderhöhen erhältlich
Status Auslaufartikel

Alles lesen

Schließen

Individuelle Gestaltung des Produkts

Aufgrund unserer flexiblen hauseigenen Produktion können Sie diesem Produkt einen individuellen Charakter verleihen. Wir zeigen Ihnen hier einige mögliche Sonderausführungen, prüfen aber auch gerne gemeinsam mit Ihnen andere Optionen.

Möglichkeiten zur individuellen Gestaltung:

  • Standrohr in Sonderhöhe

Zubehör und Netzteile

Zubehör (1)

Kabel

Gemeinsam mit der Leuchte zu bestellen

WF0110

PVC-Kabel FROR 2x0,35 Ø3,5 mm

Länge nach Wunsch

Netzteile (17)

A13350VL

Konstantstromnetzteile ON/OFF

Input115-230Vac 50-60 Hz
230Vac 50-60 Hz
Output350mA Konstantstrom; max 4W
Leistung4W
DimmenNicht dimmbar
IP NetzteilIP20

A16350IP67

Konstantstromnetzteile ON/OFF

Input115-230Vac 50-60 Hz
230Vac 50-60 Hz
Output350mA Konstantstrom; max 11W
DimmenNicht dimmbar
IP NetzteilIP67

A19220TC

Konstantstromnetzteile ON/OFF

Input115-230Vac 50-60 Hz
230Vac 50-60 Hz
Output100mA Konstantstrom; max 4,1W
120mA Konstantstrom; max 5W
140mA Konstantstrom; max 5,8W
160mA Konstantstrom; max 6,6W
180mA Konstantstrom; max 7,4W
200mA Konstantstrom; max 8,3W
220mA Konstantstrom; max 9,1W
240mA Konstantstrom; max 10W
260mA Konstantstrom; max 10,8W
280mA Konstantstrom; max 11,6W
300mA Konstantstrom; max 12,4W
320mA Konstantstrom; max 13,2W
340mA Konstantstrom; max 14,1W
60mA Konstantstrom; max 2,5W
80mA Konstantstrom; max 3,3W
360mA Konstantstrom; max 15W ⚠
DimmenON/OFF
IP NetzteilIP20

A19350QL

Konstantstromnetzteile ON/OFF

Input115-230Vac 50-60 Hz
230Vac 50-60 Hz
Output350mA Konstantstrom; max 15W
DimmenON/OFF
IP NetzteilIP20

A312350IP67

Konstantstromnetzteile ON/OFF

Input115-230Vac 50-60 Hz
230Vac 50-60 Hz
Output350mA Konstantstrom; max 17W
DimmenON/OFF
IP NetzteilIP67

A312350QL

Konstantstromnetzteile ON/OFF

Input115-230Vac 50-60 Hz
230Vac 50-60 Hz
Output350mA Konstantstrom; max 17W
DimmenON/OFF
IP NetzteilIP20

ACUNI020T1

Konstantstromnetzteile ON/OFF

Input230Vac 50-60 Hz
Output350mA Konstantstrom; max 19W
250mA Konstantstrom; max 13W ⚠
24Vdc; 16W ⚠
400mA Konstantstrom; max 20W ⚠
450mA Konstantstrom; max 20W ⚠
500mA Konstantstrom; max 20W ⚠
550mA Konstantstrom; max 20W ⚠
600mA Konstantstrom; max 20W ⚠
700mA Konstantstrom; max 20W ⚠
DimmenNicht dimmbar
IP NetzteilIP20

ACUNI039T1

Konstantstromnetzteile ON/OFF

Input230Vac 50-60 Hz
Output350mA Konstantstrom; max 15W
1050mA Konstantstrom; max 39W ⚠
500mA Konstantstrom; max 21W ⚠
550mA Konstantstrom; max 23W ⚠
650mA Konstantstrom; max 27W ⚠
700mA Konstantstrom; max 29W ⚠
750mA Konstantstrom; max 31W ⚠
850mA Konstantstrom; max 35W ⚠
900mA Konstantstrom; max 37W ⚠
DimmenNicht dimmbar
IP NetzteilIP20

ACUNI042T1

Konstantstromnetzteile ON/OFF

Input230Vac 50-60 Hz
Output300mA Konstantstrom; max 13W
350mA Konstantstrom; max 15W
1000mA Konstantstrom; max 42W ⚠
1050mA Konstantstrom; max 42W ⚠
400mA Konstantstrom; max 18W ⚠
450mA Konstantstrom; max 20W ⚠
500mA Konstantstrom; max 22W ⚠
550mA Konstantstrom; max 24W ⚠
600mA Konstantstrom; max 27W ⚠
650mA Konstantstrom; max 29W ⚠
700mA Konstantstrom; max 31W ⚠
750mA Konstantstrom; max 32W ⚠
800mA Konstantstrom; max 33W ⚠
850mA Konstantstrom; max 35W ⚠
900mA Konstantstrom; max 38W ⚠
950mA Konstantstrom; max 40W ⚠
DimmenNicht dimmbar
IP NetzteilIP20

ACUNIC30T1

Konstantstromnetzteile ON/OFF

Input230Vac 50-60 Hz
Output340mA Konstantstrom; max 18W
250mA Konstantstrom; max 13W ⚠
280mA Konstantstrom; max 15W ⚠
310mA Konstantstrom; max 16,5W ⚠
370mA Konstantstrom; max 19,5W ⚠
400mA Konstantstrom; max 21W ⚠
430mA Konstantstrom; max 22,5W ⚠
460mA Konstantstrom; max 24W ⚠
490mA Konstantstrom; max 26W ⚠
520mA Konstantstrom; max 27,5W ⚠
550mA Konstantstrom; max 29W ⚠
580mA Konstantstrom; max 30W ⚠
610mA Konstantstrom; max 30W ⚠
640mA Konstantstrom; max 30W ⚠
670mA Konstantstrom; max 30W ⚠
700mA Konstantstrom; max 30W ⚠
DimmenNicht dimmbar
IP NetzteilIP20

AD018350TLT1

Dimmbares Netzteil

Input230Vac 50-60 Hz
Output350mA Konstantstrom; max 18W ⚠
DimmenPhasenanschnitt, ON/OFF
IP NetzteilIP20

AD020DALIT1

DALI dimmbares Netzteil

Output250mA Konstantstrom; max 10W
350mA Konstantstrom; max 15W
24Vdc; 16W ⚠
400mA Konstantstrom; max 17W ⚠
450mA Konstantstrom; max 19W ⚠
500mA Konstantstrom; max 20W ⚠
550mA Konstantstrom; max 20W ⚠
600mA Konstantstrom; max 20W ⚠
700mA Konstantstrom; max 20W ⚠
DimmenDALI, ON/OFF
IP NetzteilIP20

AD030DALIT1AM

Dimmbares Netzteil - DALI+PUSH

Input230Vac 50-60 Hz
Output340mA Konstantstrom; max 18W
250mA Konstantstrom; max 13W ⚠
280mA Konstantstrom; max 15W ⚠
310mA Konstantstrom; max 16,5W ⚠
370mA Konstantstrom; max 20W ⚠
400mA Konstantstrom; max 21W ⚠
430mA Konstantstrom; max 23W ⚠
460mA Konstantstrom; max 25W ⚠
490mA Konstantstrom; max 26W ⚠
520mA Konstantstrom; max 26W ⚠
550mA Konstantstrom; max 27W ⚠
580mA Konstantstrom; max 29W ⚠
610mA Konstantstrom; max 30W ⚠
640mA Konstantstrom; max 30W ⚠
670mA Konstantstrom; max 30W ⚠
700mA Konstantstrom; max 30W ⚠
DimmenPUSH, DALI, ON/OFF
IP NetzteilIP20

AD032TLT1

Dimmbares Netzteil

Input230Vac 50-60 Hz
Output350mA Konstantstrom; max 17W
12Vdc; 10W ⚠
24Vdc; 20W ⚠
28Vdc; 22W ⚠
500mA Konstantstrom; max 24W ⚠
550mA Konstantstrom; max 25W ⚠
700mA Konstantstrom; max 32W ⚠
750mA Konstantstrom; max 32W ⚠
DimmenPUSH, Phasenanschnitt, ON/OFF
IP NetzteilIP20

AD050DALIT1

DALI+PUSH+1-10V dimmbares Netzteil

Input115-230Vac 50-60 Hz
230Vac 50-60 Hz
Output350mA Konstantstrom; max 25W
1050mA Konstantstrom; max 50W ⚠
500mA Konstantstrom; max 35W ⚠
550mA Konstantstrom; max 39W ⚠
650mA Konstantstrom; max 46W ⚠
700mA Konstantstrom; max 50W ⚠
750mA Konstantstrom; max 50W ⚠
850mA Konstantstrom; max 50W ⚠
900mA Konstantstrom; max 50W ⚠
Dimmen0/1-10V, PUSH, DALI, ON/OFF
IP NetzteilIP20

AD050PUSHT1

1-10V+PUSH dimmbares Netzteil

Input115-230Vac 50-60 Hz
230Vac 50-60 Hz
Output350mA Konstantstrom; max 25W
1050mA Konstantstrom; max 50W ⚠
500mA Konstantstrom; max 35W ⚠
550mA Konstantstrom; max 39W ⚠
650mA Konstantstrom; max 46W ⚠
700mA Konstantstrom; max 50W ⚠
750mA Konstantstrom; max 50W ⚠
850mA Konstantstrom; max 50W ⚠
900mA Konstantstrom; max 50W ⚠
Dimmen0/1-10V, PUSH, ON/OFF
IP NetzteilIP20

ADUNITC

1-10V+PUSH dimmbares Netzteil

Input115-230Vac 50-60 Hz
230Vac 50-60 Hz
Output250mA Konstantstrom; max 13W ⚠
300mA Konstantstrom; max 16W ⚠
350mA Konstantstrom; max 18W ⚠
12Vdc; 11W ⚠
24Vdc; 20W ⚠
400mA Konstantstrom; max 21W ⚠
450mA Konstantstrom; max 23W ⚠
500mA Konstantstrom; max 25W ⚠
550mA Konstantstrom; max 27W ⚠
600mA Konstantstrom; max 30W ⚠
650mA Konstantstrom; max 32W ⚠
700mA Konstantstrom; max 32W ⚠
750mA Konstantstrom; max 20W ⚠
800mA Konstantstrom; max 20W ⚠
850mA Konstantstrom; max 20W ⚠
900mA Konstantstrom; max 20W ⚠
Dimmen0/1-10V, PUSH, ON/OFF
IP NetzteilIP20

Steuerelektronik (3)

ARCUNID2-01

Universal Sequencer - Niederspannungs-4-Kanal-Controller mit Konstantstrom-Ausgang

Zusätzlich zu dem Netzteil zu bestellen

Input24Vdc
48Vdc
Output

1 Kanal

Mit 48 Vdc-Eingang:; 350mA Konstantstrom; max 15,5W
Mit 24 Vdc-Eingang:; 350mA Konstantstrom; max 6,7W ⚠
Mit 24 Vdc-Eingang:; 1050mA Konstantstrom; max 20W ⚠
Mit 24 Vdc-Eingang:; 500mA Konstantstrom; max 9,5W ⚠
Mit 24 Vdc-Eingang:; 700mA Konstantstrom; max 13,3W ⚠
Mit 48 Vdc-Eingang:; 1050mA Konstantstrom; max 45W ⚠
Mit 48 Vdc-Eingang:; 500mA Konstantstrom; max 21,5W ⚠
Mit 48 Vdc-Eingang:; 700mA Konstantstrom; max 30W ⚠

2 Kanäle

Mit 24 Vdc-Eingang:; 1050mA Konstantstrom; max 40W ⚠
Mit 24 Vdc-Eingang:; 350mA Konstantstrom; max 13,3W ⚠
Mit 24 Vdc-Eingang:; 500mA Konstantstrom; max 19W ⚠
Mit 24 Vdc-Eingang:; 700mA Konstantstrom; max 26,6W ⚠
Mit 48 Vdc-Eingang:; 1050mA Konstantstrom; max 90,3W ⚠
Mit 48 Vdc-Eingang:; 350mA Konstantstrom; max 30W ⚠
Mit 48 Vdc-Eingang:; 500mA Konstantstrom; max 43W ⚠
Mit 48 Vdc-Eingang:; 700mA Konstantstrom; max 60W ⚠

3 Kanäle

Mit 24 Vdc-Eingang:; 1050mA Konstantstrom; max 60W ⚠
Mit 24 Vdc-Eingang:; 350mA Konstantstrom; max 20W ⚠
Mit 24 Vdc-Eingang:; 500mA Konstantstrom; max 28,5W ⚠
Mit 24 Vdc-Eingang:; 700mA Konstantstrom; max 40W ⚠
Mit 48 Vdc-Eingang:; 1050mA Konstantstrom; max 135W ⚠
Mit 48 Vdc-Eingang:; 350mA Konstantstrom; max 45W ⚠
Mit 48 Vdc-Eingang:; 500mA Konstantstrom; max 64,5W ⚠
Mit 48 Vdc-Eingang:; 700mA Konstantstrom; max 90,3W ⚠

4 Kanäle

Mit 24 Vdc-Eingang:; 1050mA Konstantstrom; max 80W ⚠
Mit 24 Vdc-Eingang:; 350mA Konstantstrom; max 26,6W ⚠
Mit 24 Vdc-Eingang:; 500mA Konstantstrom; max 38W ⚠
Mit 24 Vdc-Eingang:; 700mA Konstantstrom; max 53,2W ⚠
Mit 48 Vdc-Eingang:; 1050mA Konstantstrom; max 180W ⚠
Mit 48 Vdc-Eingang:; 350mA Konstantstrom; max 62W ⚠
Mit 48 Vdc-Eingang:; 500mA Konstantstrom; max 86W ⚠
Mit 48 Vdc-Eingang:; 700mA Konstantstrom; max 120W ⚠
Dimmen0/1-10V, PUSH, DALI (DT6), 10kΩ-Potentiometer , DMX512+RDM, Stand Alone
IP NetzteilIP20

EC0CEN12443520

Niederspannungs-4-Kanal-Controller mit Konstantstrom-Ausgang (350mA) für CASAMBI-Lichtsteuerung

Weiß, dynamisches weiß, RGB, RGBW, RGB+W
Zusätzlich zu dem Netzteil zu bestellen

Input24Vdc
12Vdc
Output

1 Kanal

Mit 12 Vdc-Eingang:; 350mA Konstantstrom; max 4,2W
Mit 24 Vdc-Eingang:; 350mA Konstantstrom; max 8,4W

2 Kanäle

Mit 12 Vdc-Eingang:; 350mA Konstantstrom; max 8,4W ⚠
Mit 24 Vdc-Eingang:; 350mA Konstantstrom; max 16,8W ⚠

3 Kanäle

Mit 12 Vdc-Eingang:; 350mA Konstantstrom; max 12,6W ⚠
Mit 24 Vdc-Eingang:; 350mA Konstantstrom; max 25,2W ⚠

4 Kanäle

Mit 12 Vdc-Eingang:; 350mA Konstantstrom; max 16,8W ⚠
Mit 24 Vdc-Eingang:; 350mA Konstantstrom; max 33,6W ⚠
DimmenPUSH, Casambi
IP NetzteilIP20

WFA024350

Wandler mit Kabel 350 mm

Niederspannungswandler muss mit Gleichspannungsnetzteil kombiniert werden

Input24Vdc
Output350mA Konstantstrom; max 8,4W ⚠
DimmenPWM
IP NetzteilIP20

Lichtsteuerung (2)
