River Wall 5.0

Linear profiles for outdoor applications

linear profile for outdoor applications - 60W 48Vdc - with optics - 1020 mm - pitch 50 - RGBW - DMX512+RDM

Technical data

Required brackets, not included
  • RGBW
  • CE mark for the European Union
  • UKCA mark for Great Britain
  • CB
  • EAC
  • BIS R-41105201
  • lighting fixture with LED technology
  • appliance class III
  • gross weight
    kg 5,20
  • IP66
  • IK06
  • IPS
  • DMX+RDM
  • RAL finish on request
  • Casambi control
  • F
Installation linear profile for outdoor applications
Power consumption 60W
Power supply 48Vdc
Lumen output at source 6468 lm, R: 1316 lm G: 2044 lm B: 756 lm W: 2352 lm (4000K)
Delivered lumen output 4620 lm, R: 940 lm G: 1460 lm B: 540 lm W: 1680 lm (4000K, 33°)
Datasheet
River Wall 5.0 linear profile for outdoor applications
surface mounted (ceiling, wall, floor) with brackets
Power consumption: 60W
Power supply: 48Vdc
Lumen output at source: 6468 lm, R: 1316 lm G: 2044 lm B: 756 lm W: 2352 lm (4000K)
Delivered lumen output: 4620 lm, R: 940 lm G: 1460 lm B: 540 lm W: 1680 lm (4000K, 33°)
80 power LEDs (20 power LEDs 4000K, 60 power LEDs RGB) pitch 50 mm, 50 000h L90 B10 (Ta 25°C)
LED colour: RGBW
Optics: 13°, 33°, 47°
Body material: body in anodized aluminium
Finishes: grey (RAL 9006)
RAL finish on request
Screen material: screen in tempered, transparent glass
power supply unit not included
includes 1.5 m neoprene cable, H07RN-F 2x1.0 Ø8.7 mm and 2x1.5 m neoprene cables, 05RN-F 4x0.50 Ø5.8 mm
Control system: DMX512+RDM
Ingress protection: IP66
Impact resistance: IK06
Protection systems: IPS (Intelligent Protection System) protects lighting fixtures from water infiltrations, which can occur if there are faulty junctions between the cables in outdoor or underwater applications. This innovation, patented by L&L, also guarantees electrical protection against polarity reversal, hot plugging, ESD and power surges, which can occur if there are faults in the electrical circuit
Operating temperature: -20°C — +45°C
Maximum device temperature: 45°C (Ta 25°C)
Glow wire test: 960°
Photobiological safety: photobiological safety: risk group 1 according to EN 62471:2006
Appliance class: class III
Weight: 5200 g
Dimensions: 1020x55x73 mm
Energy efficiency class: F (light source) in accordance with EU 2019/2015
Accessories: WM0811 Pair of brackets 125 mm, WM0812 Pair of brackets 275 mm
tested and approved via E.O.L. (End Of Line) test with functioning test and check of electrical power consumption
Mounting surface mounted (ceiling, wall, floor) with brackets
Number and type of LED 80 power LEDs (20 power LEDs 4000K, 60 power LEDs RGB) pitch 50 mm, 50 000h L90 B10 (Ta 25°C)
LED colour RGBW
Optics 13°, 33°, 47°
Body material body in anodized aluminium
Screen material screen in transparent, tempered glass
Finishes grey
Power supply unit power supply unit not included
Power cables includes 1.5 m neoprene cable, H07RN-F 2x1.0 Ø8.7 mm and 2x1.5 m neoprene cables, 05RN-F 4x0.50 Ø5.8 mm
Control system DMX512+RDM
Ingress protection IP66
Impact resistance IK06
Status Product being discontinued
